GOSO Door Fitting Jig Lock Door Mortise Cutter Set

● Jig to accurately cut mortices and faceplates using your power drill.
● Fast and accurate on doors from 30mm – 55mm thick.
● Can cut door hinges and also some impact plates and electric releases.
● Self-centers and clamps onto the edge of the door.
● Vertical guides, height, and depth stop to ensure you do not overrun the cut area.
● Fast carbide cutters are specially designed for a very clean cut.
● Supplied with 3 cwb cutters: 18, 22, and 25.

৳ 11,200

Description

GOSO Door Fitting Jig Lock Door Mortise Cutter Set

Technical Specifications:
Material: Aluminium die casting + bearing steel
Color: Black Box, Silver tools
Box size: 48cm x 22cm x 9cm/18.9″ x 8.7″ x 3.5″
Cutter size: ① M8*18MM ② M8*22MM ③ M8*25MM
The maximum distance of the lock body: ≥240MM
Clamping thickness: 30mm – 55mm
Maximum grooving depth: ≥140MM
Box Size: 47cm x 17cm x 9cm/18.5″ x 6.7″ x 3.5″

Features and Benefits:
● Jig to accurately cut mortices and faceplates using your power drill.
● Fast and accurate on doors from 30mm – 55mm thick.
● Can cut door hinges and also some impact plates and electric releases.
● Self centres and clamps onto the edge of the door.
● Vertical guides, height and depth stops to ensure you do not overrun the cut area.
● Fast carbide cutters are specially designed for a very clean cut.
● Supplied with 3 cwb cutters: 18, 22 and 25.
Notice:
1. Please allow 1-2mm error due to manual measurement.Pls make sure you do not mind before you bid.
2. The color may have different as the difference display,pls understand.
Package Contents:
1 x JIG1 DOOR LOCK MORTISER KIT
3 x CUTTERS(18, 22 and 25)
1 x Allen key
1 x Wrench
